Re: BCM Max Transporter 2013
When the TPMS unit is new or flashed, this is what usually happens... it happened to me...
You must load the file with the wheel pressures.
You must load the file with the wheel pressures.
- Shadow109
- Bronze Member
- Posts: 118
- Joined: Sun Aug 16, 2020 2:59 pm
- Drives: Vw t5.1 2013
- Location: Israel
Re: BCM Max Transporter 2013
Finally
My TPMS unit was already in the middle, I did move it, but that didn’t help, so I started to play with the adaptation menu and make tests, until I found the secret
I changed the value to 1, and immediately the TP numbers had showed up
My TPMS unit was already in the middle, I did move it, but that didn’t help, so I started to play with the adaptation menu and make tests, until I found the secret
I changed the value to 1, and immediately the TP numbers had showed up
-
- Gold Member
- Posts: 500
- Joined: Wed Dec 07, 2016 8:34 pm
- Drives: Polo6r/1.2TSI/DSG7, T-roc'20 1.5TSI/DSG7
- Location: Foothills of Nilgiris, India
Re: BCM Max Transporter 2013
Oh good that you found the missing link and rectified it
This adaptation channel should have been set to 1 by default. I remember not changing any values in adaptation channels when I installed direct tpms on my Polo6R. May be due to firmware flash the value was reset to 0. Anyways good to know, thank you
This adaptation channel should have been set to 1 by default. I remember not changing any values in adaptation channels when I installed direct tpms on my Polo6R. May be due to firmware flash the value was reset to 0. Anyways good to know, thank you
- Shadow109
- Bronze Member
- Posts: 118
- Joined: Sun Aug 16, 2020 2:59 pm
- Drives: Vw t5.1 2013
- Location: Israel
Re: BCM Max Transporter 2013
Its good to have so many issues, I have learned alot, I hope this helps everyone willing to retrofit TPMSpatil wrote: ↑Sat Apr 17, 2021 4:17 pm Oh good that you found the missing link and rectified it
This adaptation channel should have been set to 1 by default. I remember not changing any values in adaptation channels when I installed direct tpms on my Polo6R. May be due to firmware flash the value was reset to 0. Anyways good to know, thank you
- Shadow109
- Bronze Member
- Posts: 118
- Joined: Sun Aug 16, 2020 2:59 pm
- Drives: Vw t5.1 2013
- Location: Israel
Re: BCM Max Transporter 2013
Hello Fernando, how are you ?
I have got A new BCM
https://pasteboard.co/K1HxnXf.jpg
I have some issues when adapting keys, dose the “E” letter requires A 315 MHZ key ?
I have got A new BCM
https://pasteboard.co/K1HxnXf.jpg
I have some issues when adapting keys, dose the “E” letter requires A 315 MHZ key ?
- ciclo
- Bling Bling Diamond Member
- Posts: 7841
- Joined: Sun Feb 24, 2013 10:20 am
- Drives: 6R'13/G7.5'19
- Location: Earth ♥, sPAIN, Magiclands (Mordor).
- Contact:
Re: BCM Max Transporter 2013
Hi, how's it going?
7E0 ... 'E' is only for 434 Mhz.
Is BCM new? in this case Channel 99 = 0 (Factory mode), ... or maybe you bought a BCM for Kessy ...
7E0 ... 'E' is only for 434 Mhz.
Is BCM new? in this case Channel 99 = 0 (Factory mode), ... or maybe you bought a BCM for Kessy ...
- ciclo
- Bling Bling Diamond Member
- Posts: 7841
- Joined: Sun Feb 24, 2013 10:20 am
- Drives: 6R'13/G7.5'19
- Location: Earth ♥, sPAIN, Magiclands (Mordor).
- Contact:
Re: BCM Max Transporter 2013
We need a Russian friend to tell us what this means...
- Shadow109
- Bronze Member
- Posts: 118
- Joined: Sun Aug 16, 2020 2:59 pm
- Drives: Vw t5.1 2013
- Location: Israel
Re: BCM Max Transporter 2013
Its used, A Russian guy was selling in a decent price on drive2, the Russian words means “made in Germany”
tomorrow I well check factory mode, and I will post a scan
tomorrow I well check factory mode, and I will post a scan
- Shadow109
- Bronze Member
- Posts: 118
- Joined: Sun Aug 16, 2020 2:59 pm
- Drives: Vw t5.1 2013
- Location: Israel
Re: BCM Max Transporter 2013
Indeed factory mode was on
New Scan :-
Code: Select all
Friday,14,May,2021,12:25:14:00009
VCDS -- Windows Based VAG/VAS Emulator Running on Windows 10 x64
VCDS Version: 21.3.0.0
Data version: 20210226 DS325.0
www.Ross-Tech.com
VIN: WV1ZZZ7HZDH036544 License Plate:
Chassis Type: 7H-VN75 (7E0)
Scan: 01 03 04 08 09 10 15 17 19 20 25 37 3C 5F 65 77 0B
VIN: WV1ZZZ7HZDH036544 Mileage: 223950km-139156miles
01-Engine -- Status: OK 0000
03-ABS Brakes -- Status: OK 0000
04-Steering Angle -- Status: OK 0000
08-Auto HVAC -- Status: OK 0000
09-Cent. Elect. -- Status: OK 0000
10-Park/Steer Assist -- Status: OK 0000
15-Airbags -- Status: OK 0000
17-Instruments -- Status: OK 0000
19-CAN Gateway -- Status: OK 0000
20-High Beam Assist. -- Status: OK 0000
25-Immobilizer -- Status: OK 0000
37-Navigation -- Status: OK 0000
3C-Lane Change -- Status: Malfunction 0010
5F-Information Electr. -- Status: Malfunction 0010
65-Tire Pressure -- Status: OK 0000
77-Telephone -- Status: OK 0000
-------------------------------------------------------------------------------
Address 01: Engine (J623-CAAA) Labels:. 03L-906-022-CAA.clb
Part No SW: 03L 906 019 GF HW: 03L 907 309 M
Component: R4 2,0L EDC H44 3312
Revision: 26H44--- Serial number: 00000000000000
Coding: 01114012232400080000
Shop #: WSC 02736 790 50316
ASAM Dataset: EV_ECM20TDI01103L906019GF 003002
ROD: EV_ECM20TDI01103L906019FG_003.rod
VCID: 75E154D3D4C13F23E0-8020
No fault code found.
Readiness: 0 0 0 0 1
-------------------------------------------------------------------------------
Address 03: ABS Brakes (-----) Labels: 7E0-907-37x-MK25AXT.clb
Part No SW: 7E0 907 379 K HW: 7E0 907 379 E
Component: ESP MK25A XT H43 0110
Revision: 00H43001
Coding: 508724AD89A70A9B24A79175796210
Shop #: WSC 02736 790 49152
VCID: 3A7B87EFB55F905BCD-806E
No fault code found.
-------------------------------------------------------------------------------
Address 04: Steering Angle (G085) Labels:* 6R0-959-654.clb
Part No SW: 6R0 959 654 HW: 6R0 959 654
Component: LENKW.SENSOR H07 0070
Serial number: 11031913470358
Coding: 01
Shop #: WSC 00000 000 00000
ASAM Dataset: EV_LWSKLOVW25X 005001
ROD: EV_LWSKLOVW25X.rod
VCID: 7EF34BFFE1F77C7BB1-802A
No fault code found.
-------------------------------------------------------------------------------
Address 08: Auto HVAC (J301) Labels:| 7E5-907-047.clb
Part No SW: 7E5 907 047 BM HW: 7E5 907 047 BM
Component: Climatic-T5 H20 0505
Revision: 00001010
Coding: 0000000002
Shop #: WSC 02736 790 50316
ASAM Dataset: EV_ClimaticT5 A01003
ROD: EV_ClimaT5Basis.rod
VCID: 7BF542EBF2E5695396-802E
No fault code found.
-------------------------------------------------------------------------------
Address 09: Cent. Elect. (J519) Labels:. 7E0-937-BCM-V1.clb
Part No SW: 7E0 937 090 E HW: 7E0 937 090 E
Component: BCM PQ25 Max4 H84 0772
Revision: B9084001 Serial number: 2502 306190145
Coding: A8A0393E4E21201201280ED06EAB9ED4F08063FF608C2040320400030800
Shop #: WSC 12345 123 12345
VCID: 2D51BCB3741137E358-8078
Subsystem 1 - Part No: 5K7 955 559 B Labels: 5K7-955-559.CLB
Component: RLS 230916 03 37 0059
Coding: 0228EE
Subsystem 2 - Part No SW: 7E0 959 801 HW: 7E0 959 801 Labels: 7E0-959-80X-V1.CLB
Component: J386__TSG_FT 002 3313
Serial number: --------------------
Coding: 000000
Subsystem 3 - Part No SW: 7E0 959 802 HW: 7E0 959 802 Labels: 7E0-959-80X-V1.CLB
Component: J387__TSG_BT 002 3313
Serial number: --------------------
Coding: 000000
No fault code found.
-------------------------------------------------------------------------------
Address 10: Park/Steer Assist (J446) Labels:| 7E0-919-475.clb
Part No SW: 7E0 919 475 AA HW: 7N0 919 475
Component: PARKHILFE 8K H06 0212
Revision: -------- Serial number: 28261631000160
Coding: 108001
Shop #: WSC 02737 790 50316
ASAM Dataset: EV_VW75XParkAssis8K 001012
ROD: EV_VW75XParkAssis8K_001_VN75.rod
VCID: 71E960C3A0A913033C-8024
No fault code found.
-------------------------------------------------------------------------------
Address 15: Airbags (J234) Labels:| 5K0-959-655.clb
Part No SW: 7E0 959 655 B HW: 7E0 959 655 B
Component: VW10Airbag003 H07 0013
Revision: -------- Serial number: 003HL00DDD0.
Coding: 000000000000000000000000000000003033
Shop #: WSC 02734 790 50316
ASAM Dataset: EV_AirbaVW10BPAVN750 A01026
ROD: EV_AirbaVW10BPAVN750_VN75.rod
VCID: 356194D394417F2320-8060
No fault code found.
-------------------------------------------------------------------------------
Address 17: Instruments (J285) Labels:| 5K0-920-xxx-17.clb-SRI1
Part No SW: 7E0 920 970 N HW: 7E0 920 970 N
Component: KOMBI H04 0805
Serial number: 00000000000000
Coding: 160A01
Shop #: WSC 02737 790 50316
ASAM Dataset: EV_Kombi_UDS_VDD_RM09 A04727
ROD: EV_Kombi_UDS_VDD_RM09_004_VW36.rod
VCID: 356194D394417F2320-8060
No fault code found.
-------------------------------------------------------------------------------
Address 19: CAN Gateway (J533) Labels:. 7E0-909-901.clb
Part No SW: 7E0 909 901 HW: 7E0 937 090 E
Component: GW-K-CAN TP20 H84 0772
Revision: B9084001
Coding: 042204
Shop #: WSC 12345 123 12345
VCID: 68DF0DA79B73D2CB6B-803C
No fault code found.
-------------------------------------------------------------------------------
Address 20: High Beam Assist. (J844) Labels:| 8S0-857-511.clb
Part No SW: 7E0 857 511 F HW: 7E0 857 511 C
Component: FLA H10 0003
Revision: AA001001
Coding: 010100E200000100000000
Shop #: WSC 12345 123 12345
ASAM Dataset: EV_HighBeamAssisAU316 001004
ROD: EV_HighBeamAssisAU316.rod
VCID: 2D51BCB37C1137E358-8078
No fault code found.
-------------------------------------------------------------------------------
Address 25: Immobilizer (J334) Labels:| 5K0-920-xxx-25.clb
Part No SW: 5K0 953 234 HW: 5K0 953 234
Component: IMMO H04 0805
Serial number:
Coding: 000000
Shop #: WSC 00000 000 00000
ASAM Dataset: EV_Immo_UDS_VDD_RM09 A03710
ROD: EV_Immo_UDS_VDD_RM09_VW21.rod
VCID: 6ADB77AF8D7FE0DB7D-803E
No fault code found.
-------------------------------------------------------------------------------
Address 37: Navigation
Cannot be reached
-------------------------------------------------------------------------------
Address 3C: Lane Change (J1086) Labels:. 5Q0-907-686.clb
Part No SW: 5Q0 907 686 C HW: 5Q0 907 686 C
Component: HRE_Master H12 0080
Serial number: 0466413079
Coding: 02032102
Shop #: WSC 09003 957 00200
ASAM Dataset: EV_HREntryHella 001028
ROD: N/A
VCID: 3D718CF3AC71A763E8-8068
No ASAM data for: "EV_HREntryHella" (VN75)
2 Faults Found:
336901 - ROD - Unknown Error Code
- 00 [009]
Confirmed - Tested Since Memory Clear
Freeze Frame:
Fault Status: 00000001
Fault Priority: 6
Fault Frequency: 1
Reset counter: 3
Mileage: 223953 km
Date: 2021.05.14
Time: 10:55:04
337328 - ROD - Unknown Error Code
- 00 [009]
Confirmed - Tested Since Memory Clear
Freeze Frame:
Fault Status: 00000001
Fault Priority: 6
Fault Frequency: 1
Reset counter: 3
Mileage: 223953 km
Date: 2021.05.14
Time: 10:55:04
-------------------------------------------------------------------------------
Address 5F: Information Electr. (J794) Labels:| 5G0-035-MIB-STD2.clb
Part No SW: 5C0 035 680 G HW: 5C0 035 680 G
Component: MU-S-ND-ER H41 0478
Serial number: VWZAZ2U1668085
Coding: 0645000FBE00000011110001000D08001F0303C401200100CE
Shop #: WSC 00046 123 12345
ASAM Dataset: EV_MUStd4CTSAT 001022
ROD: EV_MUStd4CTSAT_VN35.rod
VCID: 2541449324E10FA390-8070
Data carrier:
Subsystem 1 - Part No SW: 5NA 919 866 AL HW: -----------
Component: MRM1 2020/21 --- 1420
Serial number: --------------------
3 Faults Found:
15360768 - Component Protection
U1101 00 [009] - Active
[New feature! Extended UDS fault detail is only supported by current gen. interfaces]
Confirmed - Tested Since Memory Clear
Freeze Frame:
Fault Status: 00000001
Fault Priority: 4
Fault Frequency: 1
Reset counter: 3
Mileage: 223953 km
Date: 2021.05.14
Time: 10:55:04
Voltage terminal 30: 11.6 V
0001 - Antenna 1 for Radio
B1119 13 [009] - Open Circuit
Confirmed - Tested Since Memory Clear
Freeze Frame:
Fault Status: 00000001
Fault Priority: 6
Fault Frequency: 1
Reset counter: 3
Mileage: 223953 km
Date: 2021.05.14
Time: 10:55:05
Voltage terminal 30: 11.6 V
Status of antenna 1 for radio-Antenna current: 0 mA
Status of antenna 1 for radio-Connection between radio and antenna amplifier: Open circuit
Status of antenna 1 for radio-Connection between antenna amplifier and antenna: Not available
Status of antenna 1 for radio-Reception level antenna 1: 0 dBµV
0003 - Antenna 2 for radio
B111A 13 [009] - Open Circuit
Confirmed - Tested Since Memory Clear
Freeze Frame:
Fault Status: 00000001
Fault Priority: 6
Fault Frequency: 1
Reset counter: 3
Mileage: 223953 km
Date: 2021.05.14
Time: 10:55:05
Voltage terminal 30: 11.6 V
Status of antenna 2 for radio-Antenna current: 0 mA
Status of antenna 2 for radio-Connection between radio and antenna amplifier: Open circuit
Status of antenna 2 for radio-Connection between antenna amplifier and antenna: Not available
Status of antenna 2 for radio-Reception level antenna 2: 0 dBµV
-------------------------------------------------------------------------------
Address 65: Tire Pressure (J502) Labels: 3AA-907-273.clb
Part No SW: 3AA 907 273 F HW: 5Q0 907 273
Component: RDKBERU30 H04 0011
Serial number: 30000000047437
ASAM Dataset: EV_RDKBERU30 005005
ROD: EV_RDKBERU30_005.rod
VCID: 377D9EDB8E4D8D3332-8062
No fault code found.
-------------------------------------------------------------------------------
Address 77: Telephone
Cannot be reached
End-------------------------(Elapsed Time: 03:09)--------------------------
- ciclo
- Bling Bling Diamond Member
- Posts: 7841
- Joined: Sun Feb 24, 2013 10:20 am
- Drives: 6R'13/G7.5'19
- Location: Earth ♥, sPAIN, Magiclands (Mordor).
- Contact:
Re: BCM Max Transporter 2013
Solved!
-
- New
- Posts: 22
- Joined: Thu Dec 10, 2020 9:32 pm
- Drives: Caravelle T5.1
- Location: Lincolnshire
Re: BCM Max Transporter 2013
Apologies for jumping on the back of this thread once again, I've finally got around to uploading my parameters, still no wheel sensors fitted, but I'm getting an error from the instrument cluster due to missing messages, and no TPMS display appearing or mention of pressures in the units section. I tried disabling the indirect TPMS from the ABS unit but it made no difference.
I gave it a quick google and it came back to a thread on here where it turned out the instrument cluster was not suitable, I'm guessing it'll probably be the same for me. I've tried searching for any updated flash files for my cluster and can't find anything forthcoming....so this may be the end of the road for me with TPMS
Latest autoscan here for info https://pastebin.com/HuSfrXC5
I gave it a quick google and it came back to a thread on here where it turned out the instrument cluster was not suitable, I'm guessing it'll probably be the same for me. I've tried searching for any updated flash files for my cluster and can't find anything forthcoming....so this may be the end of the road for me with TPMS
Latest autoscan here for info https://pastebin.com/HuSfrXC5
- Shadow109
- Bronze Member
- Posts: 118
- Joined: Sun Aug 16, 2020 2:59 pm
- Drives: Vw t5.1 2013
- Location: Israel
Re: BCM Max Transporter 2013
This error is not caused from your clusterTheKeymeister wrote: ↑Fri May 28, 2021 1:23 pm Apologies for jumping on the back of this thread once again, I've finally got around to uploading my parameters, still no wheel sensors fitted, but I'm getting an error from the instrument cluster due to missing messages, and no TPMS display appearing or mention of pressures in the units section. I tried disabling the indirect TPMS from the ABS unit but it made no difference.
I gave it a quick google and it came back to a thread on here where it turned out the instrument cluster was not suitable, I'm guessing it'll probably be the same for me. I've tried searching for any updated flash files for my cluster and can't find anything forthcoming....so this may be the end of the road for me with TPMS
Latest autoscan here for info https://pastebin.com/HuSfrXC5
Your BCM hardware version is H81, your BCM have to be minimum H82 to enable address 65 (tire pressure) in can getawayAddress 09: Cent. Elect. (J519) Labels:. 7E0-937-BCM-V1.clb
Part No SW: 7E0 937 090 B HW: 7E0 937 090
Component: BCM PQ25 Max4 H81 0744
-
- New
- Posts: 22
- Joined: Thu Dec 10, 2020 9:32 pm
- Drives: Caravelle T5.1
- Location: Lincolnshire
Re: BCM Max Transporter 2013
Hi, I thought it was H81 that was required! Hope I don't need to do another BCM swap Address 65 appears in the installation list anyway
Someone on T6 forum has asked me to check with ODIS for better fault information so I'll do that over the weekend and report back
Someone on T6 forum has asked me to check with ODIS for better fault information so I'll do that over the weekend and report back
- Shadow109
- Bronze Member
- Posts: 118
- Joined: Sun Aug 16, 2020 2:59 pm
- Drives: Vw t5.1 2013
- Location: Israel
Re: BCM Max Transporter 2013
If address 65 appears in your can getaway then you don’t need to change you bcm
- ciclo
- Bling Bling Diamond Member
- Posts: 7841
- Joined: Sun Feb 24, 2013 10:20 am
- Drives: 6R'13/G7.5'19
- Location: Earth ♥, sPAIN, Magiclands (Mordor).
- Contact:
Re: BCM Max Transporter 2013
TheKeymeister wrote: ↑Fri May 28, 2021 1:23 pm Latest autoscan here for info https://pastebin.com/HuSfrXC5
BCM 090B is Ok for TPMS.TheKeymeister wrote: ↑Fri May 28, 2021 5:17 pm Hi, I thought it was H81 that was required! Hope I don't need to do another BCM swap Address 65 appears in the installation list anyway
Supposedly and based on the SW update I did on my 6R IC, you need an instrument cluster with SW greater than 0405, but as I say it is supposedly.
The only thing that is available for Transporter, Diesel and MPH is
FL_7E0920970J__0720_S.frf but it is for 9Q5 and your IC 7E0920980G is 9Q4, ... you would need to get / find a flash file similar to this FL_7E0920980J__0720_S.frf ... or FL_7E0920980N__0805_S.frf
I searched but did not find.
---
